Engine Type: OHC – 2 cylinders
Valves: 4 valves
Displacement (cc): 222
Bore X Stroke (mm): 58 x 42
Full Throttle Range (RPM): 5,000 – 6,000
Rated Power (kW (PS)): 7.4
Cooling System: Water Cooled (with Thermostat)
Fuel Delivery: 1 carburettor with accelerator pump
Ignition System: Electronic PGM-IG
Starting System: Electric / Recoil starter
Exhaust System: Through propeller boss
Gear Ratio: 2.33
Propeller Rotation: Standard
Engine Trim and Tilt: Manual Tilt – 5 stages
FUNCTION: Electric Starter: Y
Battery Charging Capacity (AMP.): 12A (Electric) / 6A (Recoil)
DIMENSIONS
Transom Height (mm): SHU/SHSU/SRU:433, LHU/LHSU/LRU: 563, XRU: 703
Dry Weight (kg): SHU: 42, SHSU: 45.5, SRU: 46, LHU: 44.5, LHSU: 48, LRU: 48.5, XRU: 52.5
Overall Length (mm): 610 (Tiller) / 600 (Remote)
Overall Width (mm): 345
Overall Height (mm): Short: 1105, Long: 1235, Extra Long: 1375
